Fabric Wrapped Panels

$0.00

APS Fabric Wrapped Panels offer a versatile acoustic solution designed to enhance sound performance while complementing the overall aesthetic of a space. Panels can be manufactured using American-made EcoCore or fiberglass, providing flexibility to meet a variety of project requirements.

Choose from 10 curated fabric options available through APS, offering a range of colors and textures to coordinate with your design.

For projects requiring a specific textile, C.O.M. (Customer’s Own Material) is also accepted upon approval for suitability.

With customizable materials, fabrics, and configurations, APS Fabric Wrapped Panels provide a tailored approach to combining effective acoustics with thoughtful design.

APS Fabric Wrapped Panels offer a versatile acoustic solution designed to enhance sound performance while complementing the overall aesthetic of a space. Panels can be manufactured using American-made EcoCore or fiberglass, providing flexibility to meet a variety of project requirements.

Choose from 10 curated fabric options available through APS, offering a range of colors and textures to coordinate with your design.

For projects requiring a specific textile, C.O.M. (Customer’s Own Material) is also accepted upon approval for suitability.

With customizable materials, fabrics, and configurations, APS Fabric Wrapped Panels provide a tailored approach to combining effective acoustics with thoughtful design.

Fabric Wrapped Panels 3.png
Fabric Wrapped Panels 1.png
Fabric Wrapped Panels 2.png

Specifications

Material

  • American-Made EcoCore: 100% Polyester

    (55% PET-Recycled Fiber, 45% PET-Virgin Fiber)

  • Fiberglass: 6-7 pcf compressed fiberglass core, containing up to 6o% post consumer

    recycled glass as a percent of glass weight as certified by fiberglass

    manufacturer. Chemically hardened edges.

Standard Sizes

  • EcoCore: Custom sizes and shapes available up to 60” x 120” depending on

    fabric selected.

  • Fiberglass: Custom sizes and shapes available up to 48” x 120” depending on fabric selected.

Thickness

AME EcoCore

  • ECO-50: 0.5” (0.50”/12.5mm) - 11 pcf

  • ECO-100: 1” (1”/25mm) - 7 pcf

  • ECO-200: 2” (2”/50.8mm) - 4.7-5.0 pcf

Fiberglass

  • APS-100: 1” - 6-7 pcf

  • APS-200: 2” - 6-7 pcf

Finishes

Standard fabrics including but not limited to APS Acoustical Fabrics,

Guilford of Maine, Carnegie, Designtex.

C.O.M. accepted after approval of suitability.

*Fiberglass panel face can be chemically hardened for tackability.

Mounting Method

Adhesive & Finish Nail, Impaling Clips, Z-Clips, Edge Clips, Hook & Loop,

Snap & Button System.

Sustainability: (AME EcoCore)

  • Minimum 50 - 55% recycled content

  • MAS Certified Green

  • LEED v4.1 ID+C, BD+C

  • CHPS 2019 Core Criteria 3.0 EQ C6.1.6

Sustainability: (fiberglass)

  • 60% recycled glass

Fire Rating

  • All panel components meet or exceed class “A” requirements as determined by ASTM E-84 tunnel test

Performance

NRC Rating ASTM C423

Type A Mount

  • 0.5” AME EcoCore: 0.45

  • 1” AME EcoCore: 0.75

  • 2" AME EcoCore: 1.10

  • Material 1” Fiberglass: (6-7 pcf): 0.85

  • Fabric Wrapped 1” Fiberglass (6-7 pcf): 0.90

  • Fabric Wrapped 2” Fiberglass (6-7 pcf): 1.15

  • Material: 2” Fiberglass (6-7 pcf): 1.15

Type F25 Mount

  • 0.5” AME EcoCore: 0.65

  • 1” AME EcoCore: 0.90

  • 2” AME EcoCore: *estimated over 1.10

Warranty

AME: All products are warranted against workmanship and manufacturing defects for five (5) years from date of purchase.

Fiberglass: All products are warranted against workmanship and manufacturing defects for two (2) years from date of purchase.
