Artisan Wrapped Panels

$0.00

APS Artisan Wrapped Panels combine high-performance acoustics with vibrant, high-resolution graphics to transform sound-absorbing panels into a custom design feature. Using a dye-sublimation printing process, artwork is printed directly onto fabric, typically our Snoopy fabric, and then expertly wrapped around your choice of EcoCore or fiberglass acoustic panels.

Artisan Wrapped Panels are ideal for designs requiring exceptional detail and color clarity. From photorealistic imagery and intricate graphics to bright, bold patterns, the dye-sublimation process captures fine details and rich color for a crisp, impactful finished product.

The result is a highly customizable acoustic solution that brings together visual expression and sound control, allowing designers to make acoustics an intentional part of the overall design.

APS Artisan Wrapped Panels combine high-performance acoustics with vibrant, high-resolution graphics to transform sound-absorbing panels into a custom design feature. Using a dye-sublimation printing process, artwork is printed directly onto fabric, typically our Snoopy fabric, and then expertly wrapped around your choice of EcoCore or fiberglass acoustic panels.

Artisan Wrapped Panels are ideal for designs requiring exceptional detail and color clarity. From photorealistic imagery and intricate graphics to bright, bold patterns, the dye-sublimation process captures fine details and rich color for a crisp, impactful finished product.

The result is a highly customizable acoustic solution that brings together visual expression and sound control, allowing designers to make acoustics an intentional part of the overall design.

Dig Printed Fabric Wall Panels 3.png
Dig Printed Fabric Wall Panels.png
Dig Printed Fabric Wall Panels 4.png

Specifications

Material

  • American-Made EcoCore: 100% Polyester

    (55% PET-Recycled Fiber, 45% PET-Virgin Fiber)

  • Fiberglass: 6-7 pcf compressed fiberglass core, containing up to 6o% post consumer

    recycled glass as a percent of glass weight as certified by fiberglass

    manufacturer. Chemically hardened edges.

Standard Sizes

  • EcoCore: Custom sizes and shapes available up to 60” x 120” depending on fabric selected.

  • Fiberglass: Custom sizes and shapes available up to 48” x 120” depending on fabric selected.

Finish

Artisan Digitally Wrapped Panels utilize a dye-sublimation printing process, where custom artwork is printed directly onto fabric, typically our Snoopy fabric, and expertly wrapped around your choice of EcoCore or fiberglass acoustic panels.

Thickness

AME EcoCore

  • ECO-50: 0.5” (0.50”/12.5mm) - 11 pcf

  • ECO-100: 1” (1”/25mm) - 7 pcf

  • ECO-200: 2” (2”/50.8mm) - 4.7-5.0 pcf

Fiberglass

  • APS-100: 1” - 6-7 pcf

  • APS-200: 2” - 6-7 pcf

Mounting Method

Adhesive & Finish Nail, Impaling Clips, Z-Clips, Edge Clips, Hook & Loop,

Snap & Button System.

Sustainability

AME EcoCore

  • Minimum 50 - 55% recycled content

  • MAS Certified Green

  • LEED v4.1 ID+C, BD+C

  • CHPS 2019 Core Criteria 3.0 EQ C6.1.6

Sustainability

Fiberglass

  • 60% recycled glass

Fire Rating

  • All panel components meet or exceed class “A” requirements as determined by ASTM E-84 tunnel test

Performance

NRC Rating ASTM C423

Type A Mount

  • 0.5” AME EcoCore: 0.45

  • 1” AME EcoCore: 0.75

  • 2" AME EcoCore: 1.10

  • Material 1” Fiberglass: (6-7 pcf): 0.85

  • Fabric Wrapped 1” Fiberglass (6-7 pcf): 0.90

  • Fabric Wrapped 2” Fiberglass (6-7 pcf): 1.15

  • Material: 2” Fiberglass (6-7 pcf): 1.15

Type F25 Mount

  • 0.5” AME EcoCore: 0.65

  • 1” AME EcoCore: 0.90

  • 2” AME EcoCore: *estimated over 1.10

Warranty

AME: All products are warranted against workmanship and manufacturing defects for five (5) years from date of purchase.

Fiberglass: All products are warranted against workmanship and manufacturing defects for two (2) years from date of purchase.
